April 200376-100016-002
PEGAsys™ LV
3-7
3-3.15 PEGAsys Addressable Loop Module (PALM)
Used in conjunction with an ORION™ XT, the PEGAsys
Addressable Loop Module permits direct connection of a
High-Sensitivity Smoke Detector (HSSD) to the signaling
line circuit of the PEGAsys LV Control Unit. Detailed infor-
mation about the PALM can be found in the ORION XT
installation, operation and maintenance manual, P/N 06-
236005-401.
The PALM allows an HSSD to be monitored like a
SmartOne initiating device. Both pre-alarm and alarm sig-
nals are reported.
400 Main Street
Ashland, MA 01721
Figure 3-15. PALM Interface Module for
ORION XT HSSD
The ORION XT HSSD is configured via a computer run-
ning ORION Configuration Software (OCS), Version 2.0.
All configuration data and smoke history is stored in the
ORION XT.
OCS may also be used to set the PALM RX/TX loop ad-
dress; however, if the address is set in this fashion, it must
then be 'Registered' at the PEGAsys CCM. PALM loop
addresses may also be set from the CCM (default setting
is 1000) in the same fashion as other loop modules.
Note: PALM addresses cannot be set via the hand-held
programmer (P/N 74-200013-001).
3-3.16 Addressable AlarmLine Module
The Addressable AlarmLine Module (AAM) permits an
AlarmLine sensor cable to be directly interfaced to the
PEGAsys LV Control Unit. Refer to Appendix M for a full
description of this Module.
TM
Figure 3-16. Addressable AlarmLine Module
3-3.17
Addressable Signal/Sounder Module
The Addressable Signal/Sounder Module (ASM) permits
notification appliances to be controlled via commands is-
sued from the PEGAsys LV Control Unit’s signaling line
circuit. The ASM is designed to mount in a standard elec-
trical box. See Appendix K for additional details on the Ad-
dressable Signal/Sounder Module.
A B BA
-+-+
+ - - +
KIDDE-FENWAL, INC.
ASHLAND, MA 01721 U.S.A.
CAT. NO. 70-200200-001
INSTRUCTIONS P/N 06-235717-001
INSTRUCTIONS P/N 06-235717-001
ALL OTHERS - POWER LIMITED
ALL OTHERS - POWER LIMITED
DEVICE
ADDRESS #
____
AUX./AUDIO MODE
SETTINGS
PC LINE TERMINALS - POWER LIMITED
PC LINE TERMINALS - POWER LIMITED
ADDRESSABLE SIGNAL/SOUNDER MODULE (ASM)
ADDRESSABLE SIGNAL/SOUNDER MODULE (ASM)
____
INSTRUCTIONS P/N 06-235717-001
INSTRUCTIONS P/N 06-235717-001
ADDRESS #
SETTINGS
AUDIO
P1=1&2
MODE
S1=3 ON
AUX. IN
+ - + -
TROUBLE
CKT.
-
OUTPUT CKT.
-+ +
AUX./AUDIO MODE
AUXILIARY
MODE
P1=2&3
S1=1&2 ON
PC LINE
A B A B
DEVICE
ALL OTHERS - POWER LIMITED
ALL OTHERS - POWER LIMITED
CAT. NO. 70-200200-001
ASHLAND, MA 01721 U.S.A.
KIDDE-FENWAL, INC.
FM
APPROVED
R
L
U
TM
Figure 3-17. Addressable Signal/Sounder Module
