April 200376-100016-002
PEGAsys™ LV
6-1
SYSTEMS
PEGAsys LV Control Unit (includes CCM with one RX/TX Module, one Power Supply/ 76-100000-506
Charger Assembly and Enclosure)
MAIN SYSTEM COMPONENTS
Central Control Module (CCM), Single-Loop 76-100008-701
Power Supply/Charger Assembly, includes 4 Amp. Power Supply 76-100009-010
RX/TX Module 76-100005-001
Main Enclosure 76-100000-507
MODULES
Network Interface Card 76-100036-500
Remote Display Control Module 76-100000-502
Remote Display Module 76-100000-501
ATM-L Annunciator Driver Board 76-100004-032
ATM-R Relay Driver Board 76-100005-032
ADDITIONAL COMPONENTS
Battery Enclosure for Additional Batteries 76-100010-001
Battery 12V, 12 AH 06-115915-047
Battery 12 V, 17 AH 06-115915-046
Battery 12 V, 33 AH 89-100052-001
SMARTONE FIELD DEVICES
Intelligent Photoelectric Detector, Model PSD-7152 71-402001-100
Intelligent Ionization Detector, Model CPD-7052 70-402001-100
Intelligent Thermal Detector, Model THD-7252 70-404001-100
6' Universal Detector Base, Model 6SB 70-400001-100
4' Universal Detector Base, Model 4SB 70-400001-101
Addressable Contact Input Device (N.O.) 70-407008-001
Addressable Contact Input Device (N.C.) 70-407008-002
Addressable Loop Module for ORION™ XT 77-297103-000
Addressable Relay Output Device 70-408004-001
CHAPTER 6
PARTS LIST
6-1 INTRODUCTION
The PEGAsys™ LV system parts list (Table 6-1) provides
a list of all repair parts.
NOMENCLATURE PART NUMBER
Table 6-1. PEGAsys LV System Parts List
