TOS5200 45
CONFIG Settings
5
Withstanding Voltage Test
Double action feature
This feature enables you to start a test by first pressing STOP and then pressing START
within 0.5 seconds. If you do not press START within this time limit, the test does not start
(the READY LED turns off). This feature ensures that tests are started safely because it
requires you to use both the STOP and START switches.
Momentary feature
This feature enables you to perform tests only while you are pressing START. This ensures
safe testing because it means that your hand must be fixed to the panel or to an optional
RC01-TOS START switch. While this feature is on, testing stops as soon as you release
START. The stop operation is the same as if you had pressed STOP.
Using this feature with the optional RC02-TOS (two-hand-type remote control box p. 16
) provides an even higher level of safety.
Fail mode feature
This feature prevents FAIL judgments and protection modes from being cleared even when a
stop signal is sent with a command. To clear the FAIL judgment when the fail mode feature is
turned on, press STOP on the front panel.
If you are using the optional high voltage test probe (HP01A-TOS/HP02A-TOS p. 17 ),
we recommend that you turn on the fail mode feature. When a test ends with a FAIL judgment
or ends in protection mode, the FAIL judgment is not cleared even if you let go of the probe.
Thus, you can definitely check the status.
Judgment result hold time (Pass Hold)
This feature enables you to set the length of time that the TOS5200 maintains a PASS judg-
ment state. If you set Pass Hold to HOLD, the measured results remain displayed on the
screen until you press STOP. When a FAIL judgment occurs, the FAIL judgment’s measured
results remain displayed on the screen until you press STOP, regardless of the value of the
Pass Hold setting.
Buzzer volume level for PASS judgment (PASS)
You can set the volume level of the buzzer that is sounded when a PASS judgment occurs.
off (0) The double action feature is turned off (factory default setting).
on (1) The double action feature is turned on.
off (0) The momentary feature is turned off (factory default setting).
on (1) The momentary feature is turned on.
See
off (0) The fail mode feature is turned off (factory default setting).
on (1) The fail mode feature is turned on.
50 ms (0) to 5.5 s (5) 0: 50 ms (factory default setting), 1: 100 ms, 2: 200 ms, 3: 1 s,
4: 2 s, 5: 5 s
HOLD (6) The results are maintained until you press STOP.
0 to 9 0, 1, 2, 3 (factory default setting), 4, 5, 6, 7, 8, 9
