TOS5200 67
Specifications
8
Specifications
Interfaces
TOS5200
USB USB Specification 2.0
Standard type B socket
RS232C
1
Hardware D-SUB 9-pin connector (EIA-232-D compliant)
All functions except the POWER switch and key lock
Baudrate: 9600, 19200, 38400, 57600, 115200 bps
Transmission system: Start-stop synchronization
Data length: 8 bits, Stop bits: 1 bit, Parity bit: None
Program message
terminator
CR+LF during transmission, CR, LF, or CR+LF during reception
REMOTE Front-panel 9-pin MINI DIN connector.
By connecting an optional device to this connector, you can control the starting and
stopping of tests remotely.
SIGNAL I/O Rear-panel D-sub 25-pin connector
Output
specifications
Output method Open collector output (4.5 Vdc to 30 Vdc)
Output withstanding
voltage
30 Vdc
Output saturation volt-
age
Approx. 1.1 V (25 °C)
Maximum output current 400 mA (TOTAL)
Input
specifications
2
High-level input voltage 11 V to 15 V
Low-level input voltage 0 V to 4 V
Low-level input current 5 mA max.
Input time width 5 ms minimum
1 INTERLOCK+
I
If you open the positive and negative terminals, the output is turned off, and the
TOS5200 is switched to Protection mode.
Open: If the resistance between the terminals is 1.2 kΩ or greater.
Short: If the resistance between the terminals is 1 kΩ or less.
2 PM0 Panel memory selection signal.
The selection signal is latched
on the rising edge of the input
strobe signal to recall panel
memory.
* The selection of memory is pri-
oritized over TEST SEL and
AUTO SEL.
I
3 PM1
I
4 NC —
5 NC —
6 NC —
7 NC —
8 NC —
9 STB I Panel memory strobe signal input terminal.
10 TEST SEL I NA
11 AUTO SEL I NA
12 COM — Circuit common terminal.
13 INTERLOCK-
I
If you open the positive and negative terminals, the output is turned off, and the
TOS5200 is switched to Protection mode.
Open: If the resistance between the terminals is 1.2 kΩ or greater.
Short: If the resistance between the terminals is 1 kΩ or less.
14 HV.ON
O
On during testing and when a voltage remains across
the output terminals.
15 TEST O On during testing (excluding when voltage is rising or falling).
16 PASS
O
On for approximately 0.2 seconds when a PASS judgment occurs.
On continuously when the PASS HOLD time is set to HOLD.
17 U-FAIL
O
On continuously when UPPER FAIL results from judgment because a value greater
than or equal to the upper limit is detected.
PM0 PM1 Recalled panel memory number
H H Memory 1
L H Memory 2
H L Memory 3
LL
—
