68 TOS5200
Specifications
TOS5200
SIGNAL I/O (continued)
18 L-FAIL
O
On continuously when FAIL results from judgment because a value less than or
equal to the lower limit is detected.
19 READY O On when the TOS5200 is waiting (when it is in the READY state).
20 PROTECTION
O
On when protective features have activated (the TOS5200 is in the Protection
state).
21 START I Start signal input terminal.
22 STOP I Stop signal input terminal.
23 ENABLE I Start signal enable signal input terminal.
24 +24V — +24 V internal power supply output terminal; maximum output current 100 mA.
25 COM — Circuit common terminal.
STATUS SIGNAL OUTPUT Output terminal for a warning light.
+ Terminal A +24 V signal is generated from this terminal when output has been turned on.
COM +24 V circuit common terminal
1 Talk mode can be set when RS232C is in use.
2 The input signals are all low-active control. The input terminal is pulled up to +12 V by a resistor. Leaving the input terminal open
is equivalent to applying a high level signal.
Talk mode Description
0 Responds only to commands from a PC (factory default setting).
1
Automatically responds at the start and end of a test. The TOS5200 status, settings, and measured values are
returned.
Response at the
start of a test
<START>
Response at the
end of a test
Status <PASS>, <U_FAIL>, <L_FAIL>, <PROT>, or <ABOUT>
Settings,
measured values
Test number, program number, test mode, measured voltage, measured current,
test time
