TOS5200 47
CONFIG Settings
5
Withstanding Voltage Test
Test
Sets whether the 24 Vdc output is generated while tests are being performed with the test
voltage at the specified voltage value.
The 24 Vdc output is not generated during voltage rise time (Rise Time) and voltage fall time
(Fall Time).
Pass
Sets whether the 24 Vdc output is generated after a PASS judgment has occurred.
Upper Fail
Sets whether the 24 Vdc output is generated after an upper limit FAIL judgment has occurred.
Lower Fail
Sets whether the 24 Vdc output is generated after a lower limit FAIL judgment has occurred.
Ready
Sets whether the 24 Vdc output is generated while the READY LED is lit.
Protection
Sets whether the 24 Vdc output is generated while the TOS5200 is in protection mode.
Power ON
Sets whether the 24 Vdc output is generated while the POWER switch is on.
off (0) The 24 Vdc output is turned off during testing (factory default setting).
on (1) The 24 Vdc output is turned on during testing.
off (0) The 24 Vdc output is turned off during testing (factory default setting).
on (1) The 24 Vdc output is turned on during testing.
off (0) The 24 Vdc output is turned off after an upper limit FAIL judgment occurs
(factory default setting).
on (1) The 24 Vdc output is turned on after an upper limit FAIL judgment occurs.
off (0) The 24 Vdc output is turned off after an lower limit FAIL judgment occurs
(factory default setting).
on (1) The 24 Vdc output is turned on after a lower limit FAIL judgment occurs.
off (0) The 24 Vdc output is turned off while the READY LED is lit (factory default
setting).
on (1) The 24 Vdc output is turned on while the READY LED is lit.
off (0) The 24 Vdc output is turned off when the TOS5200 is in protection mode
(factory default setting).
on (1) The 24 Vdc output is turned on when the TOS5200 is in protection mode.
off (0) The 24 Vdc output is turned off when the POWER switch is turned on (fac-
tory default setting).
on (1) The 24 Vdc output is turned on when the POWER switch is turned on.
