6.2 - Advanced programming of the
automation’s movement
With this procedure, the control unit memorizes the times and power
required for opening and closing the system.
Moreover, this procedure allows for setting:
- start point of slowdowns or their deletion.
STEP ACTION RESULT
1
PUT THE DOOR TO HALF
WAY POSITION
2
PRESS THE SET BUTTON
FOR 2 SECONDS
The yellow
"set" LED
ashes (if
not, refer to
Paragraph
14.1)
3
PRESS THE RADIO
BUTTON FOR 1 SECOND
The yellow
"set" LED
turns on in
xed mode
4
THE DOOR PARTIALLY
OPENS
The yellow
"set" LED
stays on
5
THE DOOR MOVES TO
FULL CLOSING POSITION
The yellow
"set" LED
ashes
6
PRESS THE SET
BUTTON OR A BUTTON
OF A PROGRAMMED
TRANSMITTER OR
CLOSE THE WIRED
START CONTACT
The yellow
"set" LED
stays on
7
THE DOOR PERFORMS
THE OPENING OVEMENT
The yellow
"set" LED
stays on
8
PRESS THE SET
BUTTON OR A BUTTON
OF A PROGRAMMED
TRANSMITTER OR
CLOSE THE WIRED
START CONTACT TO
SET THE SLOWDOWN
START POINT (*), TO HAVE
NO SLOWDOWN, WAIT
FOR THE MOVEMENT TO
BE COMPLETED
The yellow
"set" LED
stays on
9
THE DOOR COMPLETES
THE OPENING PHASE
The yellow
"set" LED
stays on
10
PRESS THE SET
BUTTON OR A BUTTON
OF A PROGRAMMED
TRANSMITTER OR
CLOSE THE WIRED
START CONTACT
The yellow
"set" LED
stays on
11
THE DOOR PERFORMS
A FULL CLOSING
MOVEMENT
The yellow
"set" LED
stays on
12
DURING MOVEMENT:
PRESS THE SET
BUTTON OR A BUTTON
OF A PROGRAMMED
TRANSMITTER OR
CLOSE THE WIRED
START CONTACT TO
SET THE SLOWDOWN
START POINT (*), TO
HAVE NO SLOWDOWN,
WAIT FOR THE
MOVEMENT TO BE
COMPLETED
The yellow
“set” LED
stays on in
xed mode
13
THE DOOR COMPLETES
THE CLOSING PHASE
The yellow
"set" LED
turns off
14
END OF THE
PROGRAMMING
PROCEDURE
The LEDs
return to
the normal
operation
conguration
(*) Minimum slowdown time must be 3 seconds.
If the “FORCE” potentiometer is adjusted, the automa-
tion’s movement must be reprogrammed.
The red “Error” LED ashes during the automation’s
movement when a mechanical stress point is detected (this
corresponds to increased motor effort).
Adjust OBSTACLE Adjust OBSTACLE and FORCE knobs
(slightly turn them clockwise) to solve this and check gate
mechanics if necessary.
