2. Product description
ROLLS is a gearmotor designed for the automation of sectional and overhead doors.
ROLLS operates using electric power, in the event of a power failure from the electrical network, it is possible to release the gearmotor and
move the door manually.
2.1 - Operating limits
Chapter 16 (“Technical specications”) provides the data needed to determine whether the product is suitable for the intended application.
Its structural characteristics make it suitable for use on sectional and overhead doors within the limits shown in table 1.
Table 1 - ROLLS gearmotor operating limits
Model: SECTIONAL door Overhead door
ROLLS 700 Height: 3.7 m Surface: 12 m
2
Height: 3.7 m Surface: 10 m
2
ROLLS 1200 Height: 3.7 m Surface: 23 m
2
Height: 3.7 m Surface: 14 m
2
The effective suitability of ROLLS for automating a specic door depends on the degree of door leaf balancing, guide friction and other as-
pects, including occasional phenomena such as wind pressure or the presence of ice, which could obstruct leaf movement.
To establish effective conditions, the force required to move the leaf throughout its stroke must be measured to ensure that this value does not
exceed the “nominal torque” specied in section 16 (“Technical specications”); also, to avoid overheating, the control unit provides a limiter
based on engine effort and cycle duration, that intervenes when
the maximum limit is exceeded.
N.B.: 1 kg = 9.81 N, for example, 500 N = 51 kg
2.2 - Typical system
Fig. 1 shows a typical system for automating a sectional door
a ROLLS
b Photocells
c Main edge
d Flashing light with in-built aerial
e Key-operated selector switch
2.3 - List of cables
Table 2 shows the specications of the cables needed to connect up the various devices.
The cables used must be suitable for the type of installation, for instance an H03VV-F type cable is recommended for indoor applications.
Table 2 - List of cables
Connection Cable type Maximum length allowed
Flashing light with aerial No.1 2x0.5 mm
2
cable 20 m
1 RG58 type shielded cable 20 m (recommended less than 5 m)
Photocells No. 1 2x0.25 mm
2
cable for TX 30 m
No. 1 4x0.25 mm
2
cable for TX 30 m
Key-operated selector switch No. 2 2x0.5 mm
2
cables (note 1) 50 m
Note 1: a single 4x0.5 mm
2
cable can be used instead of two 2x0.5mm
2
cables.
