17. Technical specications
King Gates srl, in order to improve its products, reserves the right to modify their technical specications at any time without prior notice. In
any case, the manufacturer guarantees their functionality and suitability for the intended purposes.
All the technical characteristics refer to a room temperature of 20°C (±5°C).
ROLLS technical specications ROLLS 700 NG ROLLS 1200 NG
Type Electromechanical gearmotor for the automatic movement of garage
doors for residential use, complete with electronic control unit
Pinion Pitch 8, Z18
Peak starting torque [corresponds to the force neces-
sary to keep set the leaf in motion]
700N 1200N
Speed under no load [corresponds if "Fast" speed is
programmed]
0.17m/s
Operating limits In general, ROLLS is suitable for the automation of sectional or overhead
doors which remain within the dimensions stated in table 1.
ROLLS power supply 230Vac (±10%) 50/60Hz.
Max. absorbed power 250W 300W
Insulation class 1 (a safety grounding system is required)
ROLLS courtesy light LED
Flashing Light Output for 1 ashing light (24V, 15W)
Working temp. -20°C ÷ 55°C
Use in acid, saline or potentially explosive atmosphere No
Protection class IP 40 use only in indoor or protected environments
Dimensions 414 x 264 x h 110 mm
Guide technical characteristics
Code Transmission type Guide length Door maximum height Type of guide
Grb 3
Belt
3 m 2.40 m 1 x 3 m
Grb 23 3 m 2.40 m 2 x 1.5 m
Grb 35 3.5 m 2.90 m 1 x 3.5 m
Grb 4 4 m 3.40 m 3 m + 1 m
Grb 425 4.25 m 3.70 m 1 x 4.25 m
Resistance to traction 1200 N
Incorporated radio receiver technical specications
Type 4 channel receiver for incorporated radio command
Frequency 433.92 MHz
Coding King
Transmitter compatibility (*) DigyPad, Stylo 4K, Myo C4, Novo TX and Novo Digy
No. of transmitters that can be memorised 170
Input impedance 50 Ω
Sensitivity better than 0.5µV
Range of the transmitters From 100 to 150m. The range can vary if there are obstacles or electromagnetic distur-
bances, and is also affected by the position of the receiving aerial
Outputs /
Working temp. -20°C ÷ 55°C
