29
EN
Contents
1. General warnings 30
1.1 - Safety warnings 30
1.2 - Installation warnings 30
2. Product description 32
2.1 - Operating limits 32
2.2 - Typical system 32
2.3 - List of cables 32
2.4 - Main features of the control unit 33
2.3 - Technical features of the control unit 33
3. Installation 34
3.1 - Preliminary checks 34
3.2 - Fitting 34
3.2.1 - Assembly of the supplied GRB23 guide 34
3.2.2 - Assembly of the supplied GRB3 guide 35
3.2.3 - Fitting the gearmotor to the guide 36
3.2.4 - Mounting the gearmotor to the ceiling 36
3.3 - Installation of other devices 37
3.4 - Electrical connections 37
3.5 - Description of the electrical connections 38
3.6 - Connection to the mains 38
3.7 - Electronic control unit 38
4. Control unit setting 39
4.1 - Dip-switch adjustment 39
4.2 - Potentiometer adjustment 39
5. Transmitter (remote control unit) programming 40
5.1 - Start button programming 40
5.2 -
Programming the button linked to the “Lock/AUX” output
40
5.3 -
Programming the button linked to the on-board courtesy light
41
5.4 - Deleting all memorised transmitters 41
5.5 - Deleting a single transmitter 41
5.6 - Remote (tools free) transmitter programming 41
6. Programming the door path 42
6.1 - Basic programming of the automation’s movement 42
6.2 -
Advanced programming of the automation’s movement
43
7. Testing and commissioning 44
8. LED indication 44
8.1 - Input status LED indication 44
8.2 - Error status LED 44
9. RESET procedure 45
10. Devices connectable to the control unit 46
10.1 - Warning light 46
10.2 - AUX output contact 46
10.3 - Safety devices 46
10.4 - 24VDC accessories’ power supply 47
10.5 - Wired commands 47
10.6 - Antenna 47
11. Advanced programming (*) 48
12. Back-jump adjustment 48
13. AUX output programming 49
13.1 - Selection of AUX output and operating mode 49
13.2 -
Selection of the type of devices connected to “S1 Edge”
50
14. Other functions 50
14.1 -
Activating/deactivating the control unit protection device
50
15. F.A.Q. 51
16. Disposal 52
16.1 - Scrapping the product 52
16.2 - Spent battery disposal 52
17. Technical specifications 53
18. CE Declaration of conformity 54
Note: Professional programming is not required for standard installations. When special functions and adjustments are required, refer to the
advanced/professional programming in the instruction manual (supplied with the unit and available on our website).
