- 21 -
PAS sensor direction setting
5.14.5.2 PAS sensor sensitivity setting
The display shows SCN, indicating the sensitivity of the PAS sensor. The setting
range is 2-9. 2 indicate the highest sensitivity and 9 indicate the lowest sensitivity.
Increase/decrease setting values by UP/DOWN. Press MODE to confirm and
enter the PAS sensor proportion parameter setting interface. The factory default
value is 2.
PAS sensor sensitivity setting
5.14.5.3 PAS Sensor Proportion Parameter Setting
n- represents the PAS sensor proportional parameter. The PAS sensor parameter
values can be selected by UP/DOWN. The larger the value, the more obvious the
PAS feeling. Hold MODE to confirm and return to the personalized parameter
setting interface.
