A. SD Slot - Allows you to connect a memory card, SD, SDHC, SDXC or microSD, microSDHC,
microSDXC (with included adapter)
B. USB 2.0 Port - Allows you to connect an external USB Storage Device (up to 2TB). It also allows
you to charge your mobile device.
C. Power Button - Powers on or powers off the MLWG3 device.
D. Reset Button - Resets the MLWG3 device back to its original (default) configuration. (Hold
button down for 13 seconds to reset).
E. Bridged LED - Indicates whether or not MLWG3 is bridged to an Internet gateway via Wi-Fi or
Ethernet connection.
F. Wi-Fi LED - Indicates current status of Wi-Fi broadcast.
G. Battery LED/Power* - Indicates current battery status and current power state.
H. Micro-B USB Port - For charging the MLWG3 with the included USB cable.
I. Ethernet port - Allows you to connect an Ethernet cable to create an access point for wireless
internet access.
*
The Battery LED/Power also indicates how much battery time is left while the MLWG3 is powered on. Green indicates 51% -
100%; orange indicates 25% - 50%; and red indicates less than 25% battery charge remaining.
