1.5 Name of Each Part and Its Function
1.5.1 Front view
1.5.2 Rear view
RS232C
SCSI
Interface 8
Ground
(Option)
Operation Panel
Original Guide
Original Table
Lever
Power Switch
Trays
Move the original along the Original
Guide to avoid original's skewing.
Pull up the Lever to unlock
and open the Upper Unit.
Original Receivers
