Kirisun DP990 - Page 14

DP990 DMR Two Way Radio User Manual
No.
Part Name
No.
Part Name
No.
Part Name
1
Antenna
10
Belt Clip
19
Up Key
2
Side Key 1
11
Digital Key
20
LCD Display Screen
3
PTT Key
12
Battery Latch
21
Comm Port
4
Side Key 2
13
Battery
22
LED Indicator
5
Menu/OK Key
14
Hang-up /Menu Key
23
Power/Volume Knob
6
Left Key
15
Right Key
24
Channel Selector Knob
7
Dial Key
16
Return Key
25
Top Key
8
Speaker
17
Cover Screw
-
-
9
Down Key
18
Microphone
-
-
