KitchenAid 2013 Stainless Steel Tall Tub Dishwasher
INSTALLATION
Remove towel from dishwasher. Reinstall the lower dish rack.
If needed, see website for animated representation of this step.
Visit www.kitchenaid.com/anchoring under FAQ tab.
Bottom Sound Pad Installation
(on some models)
1. Remove the bottom sound pad from inside the dishwasher
and take it out of the plastic bag.
2. Place pad on the floor in front of the dishwasher, making sure
lettering is facing up and vinyl pad faces down.
3. Fold up and hold the side panels down. Slowly slide the pad
toward the back of the dishwasher as far as it will go, making
sure not to push or pull any wires or hoses. (Do not force.)
Side panels will open to proper position.
NOTE: If there are pipes or other obstructions coming up
through the floor, you will need to cut a slit in the pad to fit
around the obstacle.
4. Fold the front end of the pad up into position. Make sure the
vinyl pad is tucked up behind the door and the dishwasher
front legs, as shown.
Complete Installation
Option A, Install Access Panel - Plastic Panel
Place the plastic access panel against the dishwasher leg.
Check that the lower edge of the access panel touches the floor.
Adjust if necessary.
Using a flat-blade screwdriver, turn the fasteners ¹⁄₄ turn
clockwise
to lock into place. The fasteners slot will be straight up and down
when properly locked.
