COMPONENT ACCESS
KitchenAid 2013 Stainless Steel Tall Tub Dishwasher
n
4-19
Heater
Heater Components
A. Heater Element Assembly
B. Rubber Washer
C. Heater Element Nut
D. Speed Nut
E. Heater Probe Shield
A
B
C
D
E
Heater
Connection
Heater
Connection
Figure 1
Figure 2
