4-8
n
KitchenAid 2013 Stainless Steel Tall Tub Dishwasher
COMPONENT ACCESS
4. Slide the electronic control to the le to unhook the tabs
on the back of the control from the slots in the door
bracket, see gures 2 and 3.
1. Unplug dishwasher or disconnect power.
2. Remove the outer panel from the door.
3. Disconnect harness(es) from control board.
3. Li up locking tab, see gure 1
Figure 1
Removing Electronic Control Board
Electrical Shock Hazard
Disconnect power before servicing.
Failure to do so can result in death or
electrical shock.
Replace all parts and panels before operating.
Figure 2
Figure 3
NOTE: There are two tabs on the back of the control that hook
into slots in the door bracket.
Tab Slots
To Next Page
