KitchenAid KUDE20FB*0 - Removing Lower Spray Arm

COMPONENT ACCESS
KitchenAid 2013 Stainless Steel Tall Tub Dishwasher
n
4-13
3. Li o, see gure 3.
To remove the lower spray arm:
1. Lower spray arm nut locaon, see gure 1.
2. Rotate the lower spray arm nut ¼ turn counter clockwise
to remove the spray arm, see gure 2.
Figure 1
Figure 2
Lower Spray Arm Assembly
Water Jets
Nut
Removing Lower Spray Arm
Figure 3
