KitchenAid 2013 Stainless Steel Tall Tub Dishwasher
COMPONENT ACCESS
1. Unplugdishwasherordisconnectpower.
2. Removetheouterpanelfromthedoor.
3.Removeuserinterfaceassemblyfromdoorpanel.
4. Disconnecttheuserinterfacewiringharness,andonsome
models,theLEDstatuslightharness,seegures2and3.
Control Board and User Interface
Removing User Interface
WARNING
Electrical Shock Hazard
Disconnect power before servicing.
Failure to do so can result in death or
electrical shock.
Replace all parts and panels before operating.
Figure 1
Figure 2
Figure 3
Figure 4

UserInterface
StatusLEDBoard
(ifavailable)
Control & UI Components
A. Console Assembly
B. Control Clip
C. Box Connector
D. Screw
E. Latch Assembly
F. Electronic Control
G. Connector Brace
H. Status Light
I. 4-Wire Jumper
F
C
D
E
A
B
G
I
H
NOTE: Thisgurerepresents
theconguraonforcapacive
touchUIandstatusLEDboard.
Connectorconguraonmayvary
dependingonmodelandUI.

