KitchenAid 2013 Stainless Steel Tall Tub Dishwasher
COMPONENT ACCESS
Under the Tub Components
Adjustable
Wheels
VS Wash
Motor
Heater
OWI / NTC
Junction Box
Overfill/Float Valve
VS Drain Motor
Fill Valve
Figure 1
Diverter Motor
& Switch
