KitchenAid KUDE20FB*0 - Removing Optical Water Indicator

COMPONENT ACCESS
KitchenAid 2013 Stainless Steel Tall Tub Dishwasher
n
4-23
Figure 4
Figure 1
Figure 2
Figure 3
Opcal water indicator–exterior view, see gure 1.
Opcal water indicator in sump area, see gure 2.
1. Rotate opcal water indicator counter-clockwise 1/4 turn,
see gure 3.
2. Pull out to remove, see gure 4.
Removing Optical Water Indicator
WARNING
Electrical Shock Hazard
Disconnect power before servicing.
Failure to do so can result in death or
electrical shock.
Replace all parts and panels before operating.
