KitchenAid KUDE20FB*0 User Manual

5-2
n
KitchenAid 2013 Stainless Steel Tall Tub Dishwasher
DIAGNOSTICS & TROUBLESHOOTING
For Service Technician Use Only
Voltage Measurement Safety Information
When performing live voltage measurements, you must do the following:
n Verifythecontrolsareintheoffpositionsothattheappliancedoesnotstartwhenenergized.
n Allowenoughspacetoperformthevoltagemeasurementswithoutobstructions.
n Keepotherpeopleasafedistanceawayfromtheappliancetopreventpotentialinjury.
n Alwaysusethepropertestingequipment.
n Aftervoltagemeasurements,alwaysdisconnectpowerbeforeservicing.
IMPORTANT: Electrostatic Discharge (ESD) Sensitive Electronics
ESD problems are present everywhere. Most people begin to feel an ESD discharge at approximately
3000V. It takes as little as 10V to destroy, damage, or weaken the main control assembly. The new
main control assembly may appear to work well after repair is nished, but a malfunction may occur
at a later date due to ESD stress.
n Use an anti-static wrist strap. Connect wrist strap to green ground connection point or unpainted
metal in the appliance
-OR-
n Touch your nger repeatedly to a green ground connection point or unpainted metal in the
appliance.
n Before removing the part from its package, touch the anti-static bag to a green ground
connection point or unpainted metal in the appliance.
n Avoid touching electronic parts or terminal contacts; handle electronic control assembly by
edges only.
n When repackaging main control assembly in anti-static bag, observe above instructions.
IMPORTANT SAFETY NOTICE — “For Technicians only”
This service data sheet is intended for use by persons having electrical, electronic, and mechanical
experience and knowledge at a level generally considered acceptable in the appliance repair trade.
Any attempt to repair a major appliance may result in personal injury and property damage. The
manufacturer or seller cannot be responsible, nor assume any liability for injury or damage of any
kind arising from the use of this data sheet.
WARNING
Electrical Shock Hazard
Disconnect power before servicing.
Failure to do so can result in death or
electrical shock.
Replace all parts and panels before operating.
DANGER
Electrical Shock Hazard
Only authorized technicians should perform
diagnostic voltage measurements.
After performing voltage measurements,
disconnect power before servicing.
Failure to follow these instructions can result in
death or electrical shock.

KitchenAid KUDE20FB*0 Specifications

General

Brand	KitchenAid
Model	KUDE20FB*0
Category	Dishwasher
Language	English
