Klimor HMI Compact - English

48
AUTOMATION AND CONTROLLER FOR UNITS EVO-T; EVO-T COMPACT
OPERATION AND MAINTENANCE MANUAL
CONTENTS
1. CONTROLLER 49
1.1 Desctription of the controller elements 49
1.2 Example of controller IN/OUT connection 50
1.3 Standard functions of controller I/Os 51
2. CONTROL CABINET CODING 52
3. CONTROL OPERATION 53
3.1 Starting-up the system 53
3.2 Changing set temperature 54
3.3 Standby mode 54
3.4 Alarms 55
4. CONTROLLER OPERATION 59
4.1 Main menu 59
4.2 Timer 59
4.3 Settings 60
4.4 Service menu 64
5. CONTROLLER OPERATION 65
5.1 Communication of RS485 Master, Modbus RTU
with the BMS system 65
5.2 Bacnet MS-TP communication with the BMS system 79
5.3 Control via WWW 79
5.4 List of EVO-T inverter addresses 80
6. CONTROL PANEL 81
6.1 HMI COMPACT Control Panel 81
6.1.1 Technical data 81
6.1.2 Connector description 81
6.1.3 Wall mounting 81
6.1.4 Controller connection diagram: 81
6.1.5 Operation 82
6.1.6 HMI screens 82
6.1.7 HMI Menu 82
6.1.8 HMI control 83
6.1.9 Alarms menu 83
6.1.10 Settings menu 84
6.2 HMI touch control panel TP4,3`` or HMI TP7``. 85
6.2.1 Technical data HMI TP4,3” HMI TP7” 85
6.2.2 Diagram of connection of HMI to the controller
HMI TP4,3” HMI TP7” 85
6.2.3 Wall mounting 86
6.2.4 TP HMI graphics screen control 86
6.2.5 HMI Menu 86
6.2.6 HMI Control 87
6.2.7 Alarm menu 87
6.2.8 Settings menu 88
7 HE ELECTRIC HEATER CONTROL MODULE 85
8. STARTUP REPORT 91
