Group Name
Default
value
Description / Settings menu
Fans
Pressure control [PI
constant pressure].
0.1 Kp_ constant airow - amplication of the constant airow regulator
30s Ti_ constant airow - constant integration of the constant airow regulator
Pressure control
Supply
air B18
Setpoint pressure 1 gear - setpoint pressure in the supply part for operation in 1 gear
Setpoint pressure 2 gear - setpoint pressure in the supply part for operation in 2 gear
Setpoint pressure 3 gear - setpoint pressure in the supply part for operation in 3 gear
The range of the sensor - the measuring range of the dierential pressure sensor - must correspond to the range selected on the sensor.
Airow setpoint 1 gear - setpoint value of airow in the supply part for operation in 1 gear (converted from pressure and K factor)
Airow setpoint 2 gear - setpoint value of airow in the supply part for operation in 2 gear (converted from pressure and K factor)
Airow setpoint 3 gear - setpoint value of airow in the supply part for operation in 3 gear (converted from pressure and K factor)
K Parameter - supply fan factor, required for the conversion of airow from the pressure
Number of supply fans - calculated cumulative set-up and measurement ow of all supply fans
Exhaust
B19
Setpoint pressure 1 gear - setpoint pressure in the exhaust part for operation in 1 gear
Setpoint pressure 2 gear - setpoint pressure in the exhaust part for operation in 2 gear
Setpoint pressure 3 gear - setpoint pressure in the exhaust part for operation in 3 gear
The range of the sensor - the measuring range of the dierential pressure sensor - must correspond to the range selected on the sensor.
Airow setpoint 1 gear - setpoint value of airow in the exhaust part for operation in 1 gear (converted from pressure and K factor)
Airow setpoint 2 gear - setpoint value of airow in the exhaust part for operation in 2 gear (converted from pressure and K factor)
Airow setpoint 3 gear - setpoint value of airow in the exhaust part for operation in 3 gear (converted from pressure and K factor)
K Parameter - exhaust fan factor, required for the conversion of airow from the pressure
Number of exhaust fans - calculated cumulative set-up and measurement ow of all exhaust fans
RS485 [Supply]
70% Min air supply airow – setting of the 1st speed airow
85% Medium air supply airow – setting of the 2nd speed airow
100% Max air supply airow – setting of the 3rd speed airow
Inactive RS485 supply inverter - activation of communication with supply fan inverter/ EC motor of the supply fan 1
Inactive RS485 supply inverter 2 - activation of communication with supply fan inverter/ EC motor of the supply fan 2
21 Supply fan inverter address - address of the supply fan EC inverter/ motor
22 Supply fan inverter address 2 - address of the supply fan EC inverter/ motor 2
RS485 [Exhaust]
70% Min air exhaust airow – setting of the 1st speed airow
85% Medium air exhaust airow – setting of the 2nd speed airow
100% Max air exhaust airow – setting of the 3rd speed airow
Inactive RS485 exhaust inverter - activation of communication with supply fan inverter/ EC motor of the exhaust fan 1
Inactive RS485 exhaust inverter 2 - activation of communication with exhaust fan inverter/ EC motor 2
31 Exhaust fan inverter address - address of the exhaust fan EC inverter/ motor 1
32 Exhaust fan inverter address 2 - address of the exhaust fan EC inverter/ motor 2
60s Acceleration time – inverters start-up time
60s Stopping time – inverters stopping time
Regulation
adjustment
-
20% Heat recovery adjustment part (editable parameter)
20% Reversible aggregate (editable parameter)
20% Mixing chamber adjustment part (editable parameter)
...% Heater/cooler adjustment part (read-only parameter)
