18
Figure 3-1 Dimensions in mm
3. Description
3.3 Functional description
The E 50 Hand Knife Sharpening Machine can be used to grind, deburr and polish hand knives in
a fully automatic process.
The hand knives are inserted in the knife magazine. On machine start, the knife gripper arm
fetches the first knife, measures and sharpens it at the grinding or polishing stations. At the end
of the grinding process, the knife is placed back in the magazine and the next one is machined.
In case of emergency, the Hand Knife Sharpening Machine can immediately be stopped by press-
ing the “Emergency Stop” button.
2389 mm
2191 mm
1391 mm
GoC GoC
