1.5 Figure and item numbers in the operating instructions
If a component of the machine that is shown in a figure is described in the text, it is followed by
a figure or item number in brackets.
Example: (7-5/1) denotes figure number 7-5, item 1.
To replace the polishing pastes, loosen the four star knobs
(7-4/3) on the side and remove the cover (7-5/1).
The used-up paste can now be replaced with new paste.
Mount the cover again and tighten the four star knobs.
1. Important notes
Figure 7-5 Changing the polishing paste
1
