29
Set the main switch (3-4/7) to “I”. Wait for the
controls to initialise.
Switch on the control unit with the “Control On”
button (6-3/1) when the “Control On” button
(6-3/1) starts flashing.
ATTENTION
Switch on the deburring and polishing unit in
the manual function (see Chapter 8.1).
Under no circumstances, activate the grind-
ing program with the “Start / Stop” program
(3-4/4).
Check the direction of rotation of the polishing
and deburring brushes.
If required, interchange the phases in the power
plug.
6. Commissioning
Figure 6-3 Control panel
Figure 6-4 Check the direction of rotation
1
