SERVICE MANUAL
28 15APR10 – SM8720-1
[2] Check the MODE BUTTON.
“Delete” 1. Press:
• “Review” BUTTON
• “Delete” BUTTON
2. Check that options display.
3. Select the “Exit” option.
4. Press:
• “OK” BUTTON to quit the “Delete” screen
• “Review” BUTTON to return to the “Auto” mode
• “Review” BUTTON again
• “Delete” BUTTON
• SHUTTER BUTTON to capture an image
5. Check:
• CAMERA quits the “Delete” screen
• image is captured
• image displays on the LCD
6. Press the “Delete” BUTTON.
7. Use the 4-WAY BUTTON to select “Yes”.
8. Press:
• “OK” BUTTON
• “Review” BUTTON
9. Use the 4-WAY BUTTON to check that the image is removed.
10. Press the “Review” BUTTON to quit.
“Zoom” 1. Press the “Zoom” BUTTON toward “T”.
2. Check that the LENS moves to the “Tele” position.
3. Press the SHUTTER BUTTON to the “S1” position.
4. Check that the image on the LCD has focus.
5. Press the SHUTTER BUTTON to capture an image.
6. Check that the image has focus.
7. Press the “Zoom” BUTTON toward “W”.
8. Check that the LENS moves to the “Wide” position.
9. Press the SHUTTER BUTTON to the “S1” position.
10. Check that the image on the LCD has focus.
11. Press the SHUTTER BUTTON to capture an image.
12. Check that the image has focus.
“Info” 1. Check that the LCD displays:
• icon for the capture mode
• icon for the flash mode
• number of additional images that can be captured
2. Press the “Info” BUTTON.
3. Check that additional icons display.
4. Press the “Info” BUTTON again to quit.
BUTTON/SWITCH Do:
