Meaning of LED behavior and lights
Wireless LED — indicated by
ECO LED — indicated by
Power LED — indicated by
•
LED lighting patterns
Blinking 1
Lights up for 1 sec.
No light for 1 sec.
Blinking 2
Lights up very rapidly
No light for more than 1 sec.
Blinking 3
Blinking very rapidly 2 times
No light for 1 sec.
Blinking 4 Blinking very slowly
Blinking 5 Blinking slowly
Blinking 6 Blinking rapidly
Blinking 7 Blinking very rapidly
Blinking 8
Blinking very rapidly 4 times
No light for 2 sec.
Blinking 9 Blinking slowly (in Power-on mode)
Unit status
LED(s) Behavior Meaning / Possible cause(s)
All LEDs No light
Unit is turned Off
or in Sleep mode, a mode which is effective in saving power.
Even in Sleep mode, the unit is able to receive a print job from USB/Network equipment.
All LEDs
Lights up
and
Blinking 9
Unit is Starting.
When you turn On, KODAK Logo with “Starting Up” and the progress bar (
) will be displayed on
the Menu display.
Lights up
Indicates that the unit is Ready.
The unit is able to receive a print job.
This Yellow LED behavior is also used when copying, scanning or cancelling copy or scan.
Blinking 5
Indicates that the unit is Running.
This Yellow LED behavior is used when printing, cancelling a print job and after the print jobs are received,
running the alignment process (While running the alignment process, any new print job received will start
printing after the alignment process is done. (The print job is not affected while the unit is scanning the
alignment pattern.)).
Blinking 1
This Yellow LED behavior is used when updating Software, restoring factory default, performing weekly
maintenance.
Red Blinking 1
System error occurred.
Refer to page 65.
Continued on next page.
