CVS-841/851 Chapter 2
Equipment Composition
Chapter 2 Equipment Composition
2.1 Standard equipment list
No Item name Type name Remarks
Weight/Length
Q’ty
CVS-841C/P With base mount 6.8 kg 1 Display
CVS-851C/P With base mount 10.5 kg
1
2 DC cable CW-253-2M For Display Unit 2m 1
3 TD cable CW-836-3M For Transducer 3m
1
4 Spare parts Detail in Spare Parts List
1 set
5 Operation
manual
English
1 set
2.2 Spare parts list
No. Item name Type name Remarks
Weight/Length
Q’ty
1 Fuse F-7161-10A
/N30C-125V
For Display Unit 1
2.3 Optional items list
No. Item name Type name Remarks Weight/Length
ST-80-1
Transom
(Plastic, with cable fitted)
0.3Kg
ST-90-1
Inner hull
(Plastic, with cable fitted)
0.6Kg
1 Temperature/
speed sensor
ST-100-1
Through hull
(Bronze, with cable fitted)
1.2Kg
J7-101
Single frequency
1.6kg
2 TD Switch
J8-201
Dual frequency
2.2kg
3 Inner hull kit
MFB-04W
Plastic, applicable for 1KW only
1.5kg
4 Kingston kit MFB-05W Applicable for 1KW only 0.83kg
5 Junction Box for
TD connections
JB-32
For dual frequency
2.0kg
JB-10 1 input, 3 outputs × 2 circuits 0.4kg 6 Junction Box
for Navigator
unit connection
JB-12
1 input, 3 outputs, 3 inputs,
1 output
0.42kg
7 AC/DC
Rectifier
PS-006
With 2 pcs of 10A fuse attached
8.0kg
VV-2D8-3M
Both ends fly leads (For power
supply)
3m
8 Extension
cable
VSV-2T11-3M Both ends fly leads (For TD)
9 Earthing lead OW7/1.6S-3M 3m
Connecting
cable
CW-371-5M
5P connector
/5P waterproof connector (LTW)
5m
10
(For external
sounder)
CW-372-5M
Fly leads/5P waterproof connector
(LTW)
5m
CW-373-5M
6P waterproof connector both
ends (LTW)
5m
11 Connecting
cable
(For navigator unit)
CW-374-5M
6P connector/6P waterproof
connector (LTW)
5m
0093132682-06 2-1
