Chapter 2 CVS-841/851
Equipment Composition
2-2 0093132682-06
No. Item name Type name Remarks Weight/Length
CW-375-5M
6P waterproof connector (Conxall)
/6P waterproof connector (LTW)
5m
(11) Connecting
cable (For
navigator unit)
CW-376-5M
Fly leads
/6P waterproof connector (LTW)
5m
CW-60-10M
BNC/Crimp terminal
10m
CW-154A-5M 6P Connector/Fly leads 5m
CW-352-5M
6P waterproof connector
(Conxall)/Crimp terminals
5m
12 Connecting
cable (For
Navigator Unit
and Junction
Box)
CW-328-5M
6P waterproof connector (Conxall) /
Crimping terminals
5m
LTWBD-05BFFA
-L180
5P waterproof connector (LTW)
for external sounder
LTWBD-06BFFA
-L180
6P waterproof connector (Conxall)
for NMEA0183
13 Connector
female
LTWBD-08BFFA
-L180
8P waterproof connector (LTW)
for 8water/temperature sensor
CG-1 For steel hull, single frequency 1.5Kg
CG-2 For steel hull, dual frequency 1.5Kg
CG-3
For wooden hull,
single frequency
2.5Kg
CG-4 For wooden hull, dual frequency 3.5Kg
CG-16 For FRP hull, single frequency 0.9Kg
CG-18
For FRP hull, dual frequency
1.8Kg
14 Cable gland
CG-19
For wooden/FRP hull,
single frequency
1.0Kg
CVS-841/851.OM.J
Japanese 15 Operation
manual
CVS-841/851.OM.E
English
CVS-841/851.SM.J
Japanese 16 Service manual
CVS-841/851.SM.E
English
17 transducer See 2.4 Available transducer list.
2.4 Available transducers list
Single Frequency TD
Output Type name Frequency Weight
TD-282 28 kHz 7.0 kg
TD-401D 38 kHz(or 40 kHz) 5.0 kg
TD-501B 50 kHz 4.2 kg
TD-751 75 kHz 4.2 kg
1 kW
TD-2001D 200 kHz 4.2 kg
TD-284 28 kHz 11.0 kg
TD-404T 38 kHz(or 40 kHz) 11.0 kg
TD-504T 50 kHz 11.0 kg
TD-504F 50kHz 10.0kg
TD-754 75 kHz 6.5 kg
3 kW
TD-66 (See NOTE) 200 kHz 4.2 kg
NOTE: The effective power output available from the 3 kW/200 KHz transducers is 1 kW.
Dual Frequency TD
Output Type name Frequency Weight
TD-501C 50/200 kHz 4.2 kg 1 kW
TD-501T-3 50/200 kHz 3.4 kg
