MDC-1840BB/1841BB/1860BB/1810BB/1820BB Series Chapter 6
Using The Menu Operation Manual
93142122-07 6-9
6.2.3.1 STAB (Screen stabilizing Mode)
Indication Meaning Selection
STAB Stabilizing Mode SEA, GND
6.2.3.2 PLOT MODE (Plotting Mode)
Indication Meaning Selection
PLOT MODE Plot Mode EPA, ATA
In this radar series, the Electronic Plotting Aid (EPA) function is installed as standard,
while the Automatic Tracking Aid (ATA) unit is an optional item. To use the ATA
function, the ATA module (PCB based) must be installed inside the processor unit.
6.2.3.3 TARGET ALL CLEAR (Plotting Target All Clear)
Using this function, all target plots can be cleared. To do so, highlight the “TARGET
ALL CLEAR” sign and press the ENT key.
Indication Meaning Selection
TARGET ALL CLR All plotted targets cleared None
6.2.3.4 ID DISP (ID Number Display)
When this item is set to ON, the target number is indicated beside the target symbol
mark.
Indication Meaning Selection
ID DISP Target ID Display OFF, ON
6.2.3.5 OUTLINE DISP (Outline Data Display)
When this item is set to ON, the course and speed data for 10 targets are indicated at
the data display area.
Indication Meaning Selection
OUTLINE DISP 10 Target Data Display OFF, ON
6.2.3.6 AIS (Automatic Identification Systems) Data Display
This function is available on option basis. For operating details, refer to Para. 6.8
“Operating the AIS.”
6.2.3.7 Navigation Display, Map function
Indication Meaning Selection
To use the EPA and ATA functions, the bearing and speed information
must be applied from an external bearing/speed sensor.
CAUTION:
