Koden MDC-1840BB - GYRO (Gyro Gear Ratio); LOG PULSE (Log Pulse Rate); Serial Input Format; SERIAL TRANSMIT (Serial Output Interval)

MDC-1840BB/1841BB/1860BB/1810BB/1820BB Series Chapter 6
Using The Menu Operation Manual
93142122-07 6-17
Table 6.3 The relation of the sentences and available device names
Sentence Talker identifier available On-screen display Device name
VD DO LOG/WT-Speed Doppler LOG
VM LOG Speed LOG, magnetic
VHW
VW LOG Speed LOG, mechanical
VBW VD DO LOG/BT-Speed Doppler LOG
VDR VD DO LOG Doppler LOG
GP GP
GPS receiver
VTG
VD DO LOG
Doppler LOG
6.4.1.5 LOG PULSE (Log Pulse Rate)
This menu is used to set up the incoming log pulse ratio, which is fed to the Gyro
Interface unit, type KSA-08A built into the processor unit.
The following pulse ratios can be selected: 100, 200, 400 and 500 pulses/nm.
Indication Meaning Selection
LOG PULSE Log pulse count for 1 NM 100, 200, 400, 500
6.4.1.6 GYRO (Gyro Gear Ratio)
This menu is used to set up the gyro gear ratio used, which is fed to the Gyro Interface
unit, type KSA-08A. The following pulse ratios can be selected: 36X, 90X, 180X and
360X.
Indication Meaning Selection
GYRO Gear Ratio for Gyro repeater 36, 90, 180, 360
6.4.1.7 Serial Input Format
This menu is used to select the type of incoming serial signal sent from external
equipment for each data input connector from DATA1 to DATA3. The following signal
formats can be selected:
SERIAL IEC61162-1, NMEA-0183,NMEA-0182,KODEN-717
6.4.1.8 SERIAL TRANSMIT (Serial Output Interval)
This menu is used to select the interval of transmission of outgoing signals.
Indication Meaning Selection
SERIAL TRANSMIT Serial Output Interval 0.1 to 9.9 SEC
