MDC-1840BB/1841BB/1860BB/1810BB/1820BB Series Chapter 4
Operation Manual Installation
0093142122-11 4-31
APPENDIX 2
Optional cables pinouts and cable color-coding designation
DATA connector pinouts and cable color coding designaltion:
Cable type name Port name Pin No. Signal name Color code
CW-376-5M DATA 1 Shield Shield, Blue
2 OUT-A White
3 OUT-B Red
4 IN-A Orange
5 IN-B Black
6 GND Green
REMOTE connector pinouts and cable color coding designaltion:
Cable type name Port name Pin No. Signal name Color code
CW-561-10M REMOTE 1 VIDEO OUT Coax. Black 1D(*)/White
2 TRIG OUT Coax. Black 2D(*)/White
3 GND Coax. Shield
4 AZIP OUT White
5 AHF OUT Yellow
6 GND Coax. Shiled
7 VIDEO IN Coax. Black 3D(*)/White
8 TRIG IN Coax. Black 4D(*)/White
9 GND Shield
10 AZIP IN Green
11 SHF IN Blue
12 +12V DC NC
NOTE for (*):
1D – 4D: This notation indicates the number of dots printed on the cable jacket.
To Next Page
