Koden MDC-1840BB - Installation Material List; Optional Items

Chapter 2 MDC-1840BB/1841BB/1860BB/1810BB/1820BB Series
Equipment Supplied Operation Manual
2-4 93142122-07
2.3 Installation material list
MDC-1841BB
No Description Rating Q’ty Use
1 Hexagonal bolt B10X25U 4 Antenna unit
2 Plain washer 2W10U 8 Antenna unit
3 Spring washer SW10U 4 Antenna unit
4 Ferrite core E04RA400270150 1 Processor unit
MDC-1840BB/1860BB/1810BB/1820BB (Common use)
No Description Rating Q’ty Use
1 Hexagonal bolt B12X55U 4 Antenna unit
2 Nut N12U 8 Antenna unit
3 Plain washer 2W12U 8 Antenna unit
4 Spring washer SW12U 4 Antenna unit
5 Ferrite core E04RA400270150 1 Processor unit
2.4 Optional items
MDC-1840BB/1841BB/1860BB/1810BB/1820BB (Common use)
No. Description Rating Remark Weight/length/Q’ty
1 Gyro/Log Interface KSA-08A
Built into the display unit
Not specified
2 ATA MRE-300 Built into the display unit Not specified
3 AIS Interface AIS-100 Built into the display unit Not specified
CW-387-5M
One end with 8-pin connector
and flying leads on the other
end
for AIS (5 m)
CW-376-5M
One end with a 6-pin
connector and flying leads on
the other end
for GPS etc.
(5 m)
CW-388-5M
One end with 10-pin
connector and flying leads on
the other end
for Gyro/Log
(5 m)
4
Navigator
connecting cable
CW-561-10M
With 12-pin connector on
both ends
for REMOTE
(10 m)
5 Display cable CW-560-2M
With 15-pin connectors on
both ends
for Display
Monitor (2 m)
6 Rectifier PS-010 With two 5 A fuses 3.5 kg
7 AC power cable VV-2D8-3M Flying leads on both ends 3 m
242J158055C-20M 20 m
242J158055D-30M 30 m
8
Connecting cable in
extra length for
RB715A
242J158055E-XM
(See NOTE)
Connectors attached on both
ends
100 m max
