1.4 System configuration
The MDC-1840BB, MDC-1841BB, MDC-1860BB, MDC-1810BB and MDC-1820BB
radar sets are configured as follows:
Refer to Figure 1 for the system configuration of this series.
MDC-1840BB
Component Unit Sub-unit Type name
Antenna Unit Not assigned
Aerial, 3-foot RW701A-03
Aerial, 4-foot RW701A-04
Transceiver RB716A (4kW)
Processor Unit MRM-100
Operation Unit MRO-100
MDC-1841BB
Component Unit Sub-unit Type name
Antenna Unit RB715A (4kW)
Processor Unit MRM-100
Operation Unit MRO-100
MDC-1860BB
Component Unit Sub-unit Type name
Antenna Unit Not assigned
Aerial, 4-foot RW701A-04
Aerial, 6-foot RW701A-06
Transceiver RB717A (6 kW)
Processor Unit MRM-100
Operation Unit MRO-100
