Chapter 6 MDC-1840BB/1841BB/1860BB/1810BB/1820BB Series
Using The Menu Operation Manual
6-4 93142122-07
6.1.5 Cursor Position
Indication Meaning
CURSOR T BRG Cursor True or Relative(R) Bearing indication
RNG Cursor Range
LAT Cursor Latitude
LON Cursor Longitude
[Data Indication]
OWN SHIP DGPS Own Ship Information (Input Device Name)
(Select with DATA DISP key)
LAT Latitude/COG/LOP1
LON Longitude/SOG/LOP2
WP RT01 DGPS Waypoint Information/Route Name/Input Device
LAT Latitude/Bearing
LON Longitude/Range
XTE Cross Track Error
DEPTH K (W) Depth
NOTE: K means the depth from the Keel, W means the depth from Water surface.
WATER TEMP Water Temperature
6.1.6 Vector Time
The vector indication mode can be set with the TRUE/REL key. A vector time can be
set from the following menu.
NOTE: To use this function the heading and latitude/longitude data must be supplied from
the gyro/log interface unit KSA-08A and a GPS or Loran-C navigator unit.
z When no bearing data is entered from the gyrocompass, the latitude and longitude
display will turn to “XXX.XX.XXX”.
z The position data may deviate when a navigator unit is used in latitude above 70
degrees.
z
To use the EPA and ATA functions, the bearing and speed information must be
supplied from external bearing and speed sensors.
CAUTION:
