Koden MDC-1840BB - Spare Parts List

MDC-1840BB/1841BB/1860BB/1810BB/1820BB Series Chapter 2
Operation Manual Equipment Supplied
93142122-07 2-3
MDC-1820BB
No. Item name Type name Remark Weight/length Q’ty
1 Aerial RW701A-04/06 4 ft / 6 ft 6 kg / 8 kg 1
2 Transceiver unit RB719A 25 kW 21 kg 1
3 Processor unit MRM-100 5.5 kg 1
4 Operation unit MRO-100 2 kg 1
5 Connecting cable 242J159098B
With connectors attached on
both ends
15 m 1
6 Power cable CW-256-2M
Cable with 5-pin connector on
one end and fly leads on the
other end
2 m 1
7 Display cable CW-560-2M
Cable with D-SUB connector
on both ends
2 m 1
8 Spare parts SP-100 See spare parts list Not specified 1 set
9 Installation materials M12-BOLT.KIT See installation material list Not specified 1 set
10 Documents
MDC-1800BSER.OME
Operation manual Not specified 1
2.2 Spare parts list
MDC-1841BB (Common use)
No Description Rating Remark Shape (Dimensions) Q’ty Use
1 Fuse 15A Normal blow
Tubular (
φ 6.3 x 32)
2 Main power supply
2 Fuse 5A Normal blow
Tubular (
φ 5 x 25)
2 Motor power supply
3 Fuse 0.3A Normal blow
Tubular (
φ 5 x 25)
2 High voltage power supply
MDC-1840BB/1860BB/1810BB/1820BB (Common use)
No Description Rating Remark Shape (Dimensions) Q’ty Use
1 Fuse 15A Normal blow
Tubular (
φ 6.3 x 32)
2 Main power supply
2 Fuse 5A Normal blow
Tubular (
φ 5 x 25)
2 Motor power supply
3 Fuse 0.3A Normal blow
Tubular (
φ 5 x 25)
2 High voltage power supply
4 Motor brush 24Z125209B Not specified Not specified 1 set Antenna motor
