Chapter 6 MDC-1840BB/1841BB/1860BB/1810BB/1820BB Series
Using The Menu Operation Manual
6-42 93142122-07
The indication and settings at CONT1
OWN OTHER
MODE INDEPENDENCE INDEPENDENCE
TYPE MASTER SLAVE
STATUS STANDBY STANDBY
The indication and settings at CONT2
OWN OTHER
MODE INDEPENDENCE INDEPENDENCE
TYPE SLAVE MASTER
STATUS STANDBY STANDBY
4. Settings for dual control radar system with using SCAN1
1st radar display unit = CONT1, scanner unit = SCAN1
2nd radar display unit = CONT2, scanner unit = SCAN1
The indication and settings at CONT1
OWN OTHER
MODE DUAL DUAL
TYPE MASTER SLAVE
STATUS STANDBY STANDBY
The indication and settings at CONT2
OWN OTHER
MODE DUAL DUAL
TYPE SLAVE MASTER
STATUS STANDBY STANDBY
6.9.4 Data output function
When using Interswitch function, one radar navigation information will be transferred
to the another radar system with NMEA0183 format. It is not necessary to connect
navigation information for both of the radar systems. The information is transferred
through DATA1 connector together with Interswitch control messages. The talker
device names of the output messages are "RA" as a radar.
