MDC-1840BB/1841BB/1860BB/1810BB/1820BB Series Chapter 6
Using The Menu Operation Manual
93142122-07 6-41
The indication and settings at CONT1
OWN OTHER
MODE INDEPENDENCE INDEPENDENCE
TYPE MASTER MASTER
STATUS STANDBY STANDBY
The indication and settings at CONT2
OWN OTHER
MODE INDEPENDENCE INDEPENDENCE
TYPE MASTER MASTER
STATUS STANDBY STANDBY
2. Settings for cross controlled two radars
1st radar display unit = CONT1, scanner unit = SCAN2
2nd radar display unit = CONT2, scanner unit = SCAN1
The indication and settings at CONT1
OWN OTHER
MODE CROSS CROSS
TYPE MASTER MASTER
STATUS STANDBY STANDBY
The indication and settings at CONT2
OWN OTHER
MODE CROSS CROSS
TYPE MASTER MASTER
STATUS STANDBY STANDBY
3. Settings for master-slave with CONT1/SCAN1 as MASTER
1st radar display unit = CONT1, scanner unit = SCAN1
2nd radar(monitor) display unit = CONT2, scanner unit = ---
