Chapter 6 MDC-1840BB/1841BB/1860BB/1810BB/1820BB Series
Using The Menu Operation Manual
6-40 93142122-07
(3) DUAL
Two display units control the scanner unit that is selected with MASTER radar on the
TYPE item. Operations for the scanner unit will effect to the other display unit
automatically.
6.9.3.2 TYPE
Set the operation type on this item.
(1) MASTER
The display unit can control a scanner unit. When the MODE is set as DUAL, the
scanner unit of this radar system will be used for the radar system.
(2) SLAVE
The display unit will operate as monitor. An external radar signals will be used for the
radar image indication.
6.9.3.3 STATUS
This item will indicate for each radar status such as STANDBY, TX(Transmit), and
WAIT.
(1) STANDBY
The radar is at stand by state.
(2) TX
The radar in transmitting.
(3) WAIT
The radar is waiting for magnetron preheating.
6.9.3.4 ANTENNA
This item will indicate for each radar antenna position on the screen such as PORT,
STBD(STarBoarD), and so on. Set the antenna position on this item.
6.9.3.5 Examples for Setting
1. Settings for normal two radars
1st radar display unit = CONT1, scanner unit = SCAN1
2nd radar display unit = CONT2, scanner unit = SCAN2
