Chapter 2 MDC-1840BB/1841BB/1860BB/1810BB/1820BB Series
Equipment Supplied Operation Manual
2-2 93142122-07
MDC-1860BB
No. Item name Type name Remark
Weight/length
Q’ty
1 Aerial RW701A-04/06 4 ft / 6 ft 6 kg / 8 kg 1
2 Transceiver unit RB717A 6 kW 17 kg 1
3 Processor unit MRM-100 5.5 kg 1
4 Operation unit MRO-100 2 kg 1
5 Connecting cable 242J159098B-15M
With connectors attached on
both ends
15 m 1
6 Power cable CW-256-2M
Cable with 5-pin connector on
one end and fly leads on the
other end
2 m 1
7 Display cable CW-560-2M
Cable with D-SUB connector
on both ends
2 m 1
8 Spare parts SP-100 See spare parts list Not specified 1 set
9 Installation materials M12-BOLT.KIT See installation material list Not specified 1 set
10 Documents
MDC-1800BSER.OME
Operation manual Not specified 1
MDC-1810BB
No. Item name Type name Remark
Weight/length
Q’ty
1 Aerial RW701A-04/06 4 ft / 6 ft 6 kg / 8 kg 1
2 Transceiver unit RB718A 12 kW 17 kg 1
3 Processor unit MRM-100 5.5 kg 1
4 Operation unit MRO-100 2 kg 1
5 Connecting cable 242J159098B-15M
With connectors attached on
both ends
15 m 1
6 Power cable CW-256-2M
Cable with 5-pin connector on
one end and fly leads on the
other end
2 m 1
7 Display cable CW-560-2M
Cable with D-SUB connector
on both ends
2 m 1
8 Spare parts SP-100 See spare parts list Not specified 1 set
9 Installation materials M12-BOLT.KIT See installation material list Not specified 1 set
10 Documents
MDC-1800BSER.OME
Operation manual Not specified 1
