Chapter 4 MDC-1840BB/1841BB/1860BB/1810BB/1820BB Series
Installation Operation Manual
4-12 0093142122-11
Screw cover (4 positions)
Operation unit
M5 (5 mm) tapping screw (4 positions)
Mounting bracket
M5 (5 mm) Screw (4 positions)
Figure 4.10 Mounting the Control unit
Figure 4.11 Service space required for the Operation unit
To Next Page
