MDC-1840BB/1841BB/1860BB/1810BB/1820BB Series Chapter 5
Operation Manual Basic Operation
0093142122-10 5-23
The SART signal presentation and its signal timing
1 nm or more beyond
the SART position
Within 1 nm of the SART position
Beam width of the
radar signal received
SART
position
Current position
Bandwidth
of the radar
Signal
received
Slow sweep signal
SART position
Fast sweep signal
Slow sweep signal
Fast sweep signal
Sweep start
9,500 MHz
9,200 MHz
7.5
μ
sec sweep time
95
μ
sec sweep time
SART mark length
