Kohler KDW 1603 - Valve Seats And Bore; Valve Recess And Sealing Surfaces

29
28
30
A 41,500÷41,520mm
B 41,575÷41,590mm
C 36,500÷36,520mm
D 36,575÷36,590
α 44°53'÷45°
α
1
59°53'÷60°
Ss* 1,27÷1,55
2,00
Sa* 1,20÷1,60
H 0,75÷1,00 1,30
6
- 43 - - 43 -
Valve seats and bore
Dimensions
Ref.
Valve recess and sealing surfaces
Ss*
=Sealingsurfacewidthonexhaustside
Sa*=Sealingsurfacewidthonintakeside
H=Valverecesswithreferencetotheheadplane
Limit value
(mm)
Dimensions
(mm)
Ref.
Workshop Manual KDW 1603_2204_2204/T _ cod. ED0053029180 - 1° ed_rev. 00
