Kohler KDW 1603 - Engines With Hydraulic Tappets

6
116
- 65 - - 65 -
1603_2204
1603_2204
2204/T
Disassembly / Reassembly
Engine typer.p.m.
Intake
Exhaust
a =8°beforeS
β =28°after I
under
2400 r.p.m.
upper
2400 r.p.m.
γ
=36°beforeI
δ =8°after S
a =12°beforeS
β =36°after I
γ =48°beforeI
δ =12°after S
under/upper
2400 r.p.m.
a =12°beforeS
β =48°after I
γ =58°beforeI
δ =14°after S
Engines with hydraulic tappets
Timing belt operating angles (with valve clearance set to zero)
Legend
S = pistonattopdeadcentre
l = pistonatbottomdeadcentre
a = intakevalveopen
β=intakevalveclosed
γ= exhaustvalveopen
δ = exhaustvalveclosed
Workshop Manual KDW 1603_2204_2204/T _ cod. ED0053029180 - 1° ed_rev. 00
