Kohler KDW 1603 - Test Data Of Injection Pump; Injection Pump P. No. 6590-249 - Plunger And Barrel Assembly; Checking Injection Pump Delivery

10
166
165
- 81 - - 81 -
0,35
9
1500
31÷41 40÷48
500 23÷33 20÷28
0 150 56÷66 58÷64
Fuel system
Injection pump P. No. 6590-249
Plunger and barrel assembly
Components:
1Pumpbody
2 Barrel
3Plunger
4Plungingblade
 
Note: Barrel2formsanintegralpartofthepumpbody1.
 Forthisreasonboththebarrelandplunger3shouldnot
bereplaced.
Test data of injection pump
Checking injection pump delivery
Components:
1
Deliveryadjustmentrod
2Rod1stopposition
3 Rod1max.deliveryposition
A =18.5÷19.5mm(rodmax.stroke)
a =66°(rodmax.rotation)
Workshop Manual KDW 1603_2204_2204/T _ cod. ED0053029180 - 1° ed_rev. 00
KDW 1603-2204
Delivery
mm
3
/stroke
KDW
2204/T
Delivery
mm
3
/stroke
Control rod
max. force
Newton
Rod stroke from
max. delivery
point (mm)
Camshaft
rpm
