Kohler KDW 1603 - Oil Pressure Check; Oil Pressure Curve For KDW 1603; Oil Pressure Curve For KDW 2204; Oil Pressure Curve For KDW 2204;T

138
136
134
133
137
135
139
8
- 72 - - 72 -
Lubrication system
Oil pressure check
Oncompletingassembly,llwithengineoil and fuel;connecta
10barpressuregaugetothepressureswitchtting.
Start the engine and check pressure as a function of the oil
temperature.
Workshop Manual KDW 1603_2204_2204/T _ cod. ED0053029180 - 1° ed_rev. 00
Oil pressure curve for KDW 2204/T
Fig.138- The curve is obtained at the oil lter level constant
engineepeedof850rpminno-loadconditions.
Fig.139- Thecurveisobtainedattheoillterlevelwithengine
workingat3000rpmattheNpower.
Note: The max lubrication oil temperature must be lower than
thesum:ambienttemperature+95°C.
Oil pressure curve for KDW 2204
Fig.136- The curve is obtained at the oil lter level constant
engineepeedof850rpminno-loadconditions.
Fig.137- Thecurveisobtainedattheoillterlevelwithengine
workingat3000rpmattheNpower.
Oil pressure curve for KDW 1603
Fig.134- The curve is obtained at the oil lter level constant
enginespeedof850rpminno-loadconditions.
Fig.135- Thecurveisobtainedattheoillterlevelwithengine
workingat3000rpmattheNpower.
