TP-6745 7/1046 Section 3 Controller Test and Replacement
3.1.4 Pushbuttons
The user interface panel has four pushbuttons below the
display. Pushbutton functions are shown above each
button in the last line of the display and can change from
screen-to-screen.
The pushbutton functions are defined in Figure 3-4.
B
Y
"
Down arrow (closed). Step down to the next
screen or scroll through a list.
Up arrow (closed). Step back to the previous
screen.
Right arrow (closed). Move to the next
submenu.
Up arrow (open). Increases the selected
numerical value.
Down arrow (open). Decreases the selected
numerical value.
Right arrow (open). Steps to the next digit in a
selected numerical value.
Back Steps back to the previous screen or submenu.
View From the main screen, moves to the first
view screen.
Set From the main screen, moves to the first
setup screen.
Test From the main screen, moves to the test
sequence screens.
End
Delay
End
Test
Start From the Test screen, starts the test sequence.
Save Saves settings shown on the display.
Main Returns to the main screen.
Next Steps to the next parameter in an item with
multiple settings (for example, in Exerciser
Setup).
OK Enters the displayed numerical value
(password or setting).
Sel Select the displayed file.
File transfer commands (USB device connected):
Del Delete the displayed file.
Upload Load the displayed file to the USB device.
Download Load the displayed file to the controller.
Reset Reset the fault condition shown on the display,
or reset an accessory module after connection.
Ends the current time delay.
Ends an active test sequence. See
Section 3.6.5.
Figure 3-4 Pushbutton Functions
