TP-6714 4/10128 Appendix
Setup Screens
Set Time/Date
D Set Time
D Set Date
D Set Automatic Daylight Saving Time
Set Exerciser
For each exerciser event:
D Enable/Disable
D Loaded/Unloaded
D Interval
D Repeat Rate
D Duration
D Start Date
D Start time
Set Prime Power Run
D Enable/Disable
D Duration at Source1 DD:HH:MM
D Duration at Source2 DD:HH:MM
D Sequence Start/Stop
Set S1 Time Delays (Set S2 Time Delays)
D Engine Start
d External Battery? Y or N
d Time Delay min:sec
D Engine Cooldown Time Delay min:sec
D Xfr Preferred>Standby (Standby>Preferred)
D Xfr Off > Standby (Off >Preferred)
(programmed--transition only)
D Fail to Acquire Preferred (Standby)
d Enable/Disable
d Time Delay min:sec
D Load Control
d Mode: None/Time/Current
d Loads to Control (1--9)
D Time-Based Control (for each connected load)
d Load Disconnect N>E (E>N) Time Delay min:sec
d Load Add E>N (N>E) Time Delay min:sec
D Current-Based Control
d Load Disc N>E (E>N) time delay min:sec
d For each connected load:
d Load Add Source1 (Source2) Time Delay min:sec
d Load Add Source1 (Source2) Priority
d Load Remove Source1 (Source2) Time Delay min:sec
d Load RemoveSource1 (Source2) Priority
d Load Control Enable/Diable
d Set Hi current Level, Load Remove Source1 (Source2)
d Set Lo Current Level, Load Add Source1 (Source2)
Set Source
D Phase Rotation ABC/BAC/Disabled
D Set In-Phase Monitor
d Enable/Disable
d Angle
d In-Phase Transfer Fail Time Delay
d Enable/Disable
d Time Delay min:sec
D Set Synchronization
d Voltage Differential
d Frequency Differential
d Angle Differential
d Fail to Sync
d Enable/Disable
d Time Delay min:sec
D Set Preferred Source Normal/Emergency
D Set Normal (Emergency) Source:
d Number of Phases
d Voltage
d Frequency
d Under Voltage Pickup
d Under Voltage Dropout
d Over Voltage Pickup
d Over Voltage dropout
d Voltage Debounce Time
d Voltage Unbalance Enable/Disable
d Voltage Unbalance Pickup
d Voltage Unbalance Dropout
d Under Frequency Pickup
d Under Frequency Dropout
d Over Frequency Pickup
d Over Frequency Dropout
d Frequency Debounce time
Set Input/Output
D Set Main Board I/O
d Set Input Functions *
d Set Output Functions [
D Set Auxiliary I/O (Modules)
d Set Input Functions *
d Set Output Functions [
* See Section 5.12.3, Input Functions
[ See Section 5.12.4, Output Fundtions.
Set Common Alarms
D Alarm Group 1 or 2
D Modify Alarm
d Common (Yes/No)
d Audible (Yes/No)
D Remove All Alarms Yes/No
